Belgium Power Cords - AC Cables

  Belgium Power Cords and Power Supply Cord Sets
Belgium Power Cords 16 Amp  FR1-16P, CEE 7/7, CEE 7/5, 16 Amp 250 Volt AC, 2 Pole 3 Wire Grounding, Type E Plug
Belgium Power Cords 2.5 Amp  CEE 7/16 (Non-Polarized) Europlug, 2.5 Amp 250 Volt AC, 2 Pole 2 Wire Non-Grounding

Specification Data: Belgium Power Cords, AC Cables, Type E Plug

Plug StandardCEE 7/7, CEE 7/5, CEE 7/16 (Non-Polarized) Type E PlugBelgium Power Cords and AC Cables
Connector StandardsIEC 60320 (320) C-13, C-13 Locking, C-19, C-19 Locking, C-5, C-7, C-15, Unterminated
Cordage StandardsH05VV-F3G, H03VV-F3G, H03VV-H2, H05VV-H2, H05VV-F2, CENELEC HD-21 (HAR)
Conductor Size / Rating0.75 mm @ 6 Ampere, 1.0 mm @ 10 Ampere, 1.5mm @ 16 Ampere
MaterialPVC, Jacket Color Black, Temperature 70C
Conductor Color CodeBrown, Blue, Green/Yellow (3 wire); Brown, Blue (2 wire)
Jacket O.D. (Approx.)6.4 mm = 3 x 0.75 mm, 7.2 mm = 3 x 1.0mm, 8.3 mm = 3 x 1.5 mm
Substances ComplianceREACH, RoHS Compliant
Power Cord Notes: Belgium Type E power cords are black as standard color. Belgium power cords in white or gray are special order. Custom length and shielded Belgium AC power cables available. Terminated, custom stripping, hanked Belgium cords available. IEC 60320 C-15 120C connector available on some Belgium AC power cords.

Belgium Power Cords - AC Cables

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Straight C-13 Connector
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Belgium plug to straight C-13 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-13
Cordage - H05VV-F3G 1.0mm - CE Mark
Part No.Rating DescriptionLength
81131 10A 250V AC Straight C-13 Connector2.5 m
81131X1FT 10A 250V ACStraight C-13 Connector 1 ft
81131X2FT 10A 250V AC Straight C-13 Connector 2 ft
81131X3FT 10A 250V AC Straight C-13 Connector 3 ft
81131X4FT 10A 250V ACStraight C-13 Connector 4 ft
81131X5FT 10A 250V AC Straight C-13 Connector 5 ft
81131X6FT 10A 250V ACStraight C-13 Connector 6 ft
81131X10FT 10A 250V AC Straight C-13 Connector 10 ft
81131X15FT 10A 250V ACStraight C-13 Connector 15 ft
81131X20FT 10A 250V AC Straight C-13 Connector 20 ft
81131X1M 10A 250V ACStraight C-13 Connector 1 m
81131X1.5M 10A 250V AC Straight C-13 Connector 1.5 m
81131X2M 10A 250V ACStraight C-13 Connector 2 m
81131X3M 10A 250V AC Straight C-13 Connector 3 m
81131X5M 10A 250V ACStraight C-13 Connector 5 m
81131-LK 10A 250V AC "Locking" Straight
C-13 Connector		 2.5 m
81131-S 10A 250V AC Straight C-13 Connector
Shielded Cordage		 2.5 m
Cordage - H05VV-F3G 1.0mm - CE Mark
Belgium plug to straight C-13 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-13

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Left-Angle C-13 Connector
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
81131-LA 10A 250V ACLeft-angle C-13 Connector2.5 m
Cordage - H05VV-F3G 1.0mm - CE Mark
Belgium plug to left-angle C-13 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-13

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Right-Angle C-13 Connector
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
81131-RA 10A 250V ACRight-angle C-13 Connector2.5 m
Cordage - H05VV-F3G 1.0mm - CE Mark
Belgium plug to right-angle C-13 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-13

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Straight C-13 Connector
CEE 7/7, CEE 7/5, Type E Down-Angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.Rating DescriptionLength
81641 10A 250V AC Straight C-13 Connector2.5 m
81641X3FT 10A 250V ACStraight C-13 Connector 3 ft
81641X6FT 10A 250V AC Straight C-13 Connector 6 ft
81641X10FT 10A 250V AC Straight C-13 Connector 10 ft
81641X15FT 10A 250V ACStraight C-13 Connector 15 ft
81641X20FT 10A 250V AC Straight C-13 Connector 20 ft
81641X1M 10A 250V ACStraight C-13 Connector 1 m
81641X1.5M 10A 250V AC Straight C-13 Connector 1.5 m
81641X3M 10A 250V ACStraight C-13 Connector 3 m
81641-LK 10A 250V AC"Locking" Straight
C-13 Connector		 2.5 m
Cordage - H05VV-F3G 1.0mm - CE Mark
Belgium down-angle plug to straight C-13 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-13

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Left-Angle C-13 Connector
CEE 7/7, CEE 7/5, Type E Down-Angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
81641-LA 10A 250V ACLeft-angle C-13 Connector2.5 m
Cordage - H05VV-F3G 1.0mm - CE Mark
Belgium down-angle plug to left-angle C-13 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-13

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Right-Angle C-13 Connector
CEE 7/7, CEE 7/5, Type E Down-Angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
81641-RA 10A 250V ACRight-angle C-13 Connector2.5 m
Cordage - H05VV-F3G 1.0mm - CE Mark
Belgium down-angle plug to right-angle C-13 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-13

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Straight C-19 Connector
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
80101 16A 250V ACStraight C-19 Connector2.5 m
80101X6FT 16A 250V ACStraight C-19 Connector6 ft
80101X10FT 16A 250V ACStraight C-19 Connector10 ft
80101X12FT 16A 250V ACStraight C-19 Connector12 ft
80101X15FT 16A 250V ACStraight C-19 Connector15 ft
80101-LK 16A 250V AC"Locking" Straight
C-19 Connector		2.5 m
Cordage - H05VV-F3G 1.5mm - CE Mark
Belgium plug to straight C-19 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-19

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Left-Angle C-19 Connector
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
80101-LA 16A 250V ACLeft-angle C-19 Connector2.5 m
Cordage - H05VV-F3G 1.5mm - CE Mark
Belgium to left-angle C-19 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-19

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Right-Angle C-19 Connector
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
80101-RA 16A 250V ACRight-angle C-19 Connector2.5 m
Cordage - H05VV-F3G 1.5mm - CE Mark
Belgium plug to right-angle C-19 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-19

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Straight C-19 Connector
CEE 7/7, CEE 7/5, Type E Down-Angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
80151 16A 250V ACStraight C-19 Connector2.5 m
80151X6FT 16A 250V ACStraight C-19 Connector6 ft
80151X10FT 16A 250V ACStraight C-19 Connector10 ft
80151X12FT 16A 250V ACStraight C-19 Connector12 ft
80151X15FT 16A 250V ACStraight C-19 Connector15 ft
80151-LK 16A 250V AC"Locking" Straight
C-19 Connector		2.5 m
Cordage - H05VV-F3G 1.5mm - CE Mark
Belgium down-angle plug to straight C-19 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-19

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Left-Angle C-19 Connector
CEE 7/7, CEE 7/5, Type E Down-Angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
80151-LA 16A 250V ACLeft-angle C-19 Connector2.5 m
Cordage - H05VV-F3G 1.5mm - CE Mark
Belgium down-angle plug to left-angle C-19 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-19

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Right-Angle C-19 Connector
CEE 7/7, CEE 7/5, Type E Down-Angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
80151-RA 16A 250V ACRight-angle C-19 Connector2.5 m
Cordage - H05VV-F3G 1.5mm - CE Mark
Belgium down-angle plug to right-angle C-19 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-19

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Straight C-5 Connector
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
81950 2.5A 250V ACStraight C-5 Connector1.8 m
81950X2.5M 2.5A 250V ACStraight C-5 Connector2.5 m
81950X3M 2.5A 250V ACStraight C-5 Connector3 m
Cordage - H03VV-F3 0.75mm - CE Mark
Belgium plug to straight C-5 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-5

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Straight C-5 Connector
CEE 7/7, CEE 7/5, Type E Down-Angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
81953 2.5A 250V ACStraight C-5 Connector1.8 m
81953X2.5M 2.5A 250V ACStraight C-5 Connector2.5 m
81953X3M 2.5A 250V ACStraight C-5 Connector3 m
Cordage - H03VV-F3 0.75mm - CE Mark
Belgium down-angle plug to straight C-5 connector - Belgium Power Cord
Belgium Power Cords, Type E Plug
FR1-16P       "CE" Mark       IEC 60320 C-5

Belgium Power Cords, Detachable Cord Sets to IEC 60320 Straight C-7 Connector
CEE 7/16 (Non-Polarized) Europlug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
81900 2.5A 250V ACStraight C-7 Connector1.8 m
Cordage - H03VV-H2-F2 0.75mm - CE Mark
Europlug to straight C-7 connector - Belgium Power Cord
Belgium Power Cords, Europlug
CEE 7/16       "CE" Mark       IEC 60320 C-7

Belgium Power Cords, Power Supply Cord Sets to Unterminated Cord End
CEE 7/7, CEE 7/5, Type E Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescription / ConductorsLength
810106A 250V ACStraight plug/0.75 mm2.5 m
8104010A 250V ACStraight plug/1.0 mm2.5 m
81040X10FT10A 250V ACStraight plug/1.0 mm10 ft
81040X12FT10A 250V ACStraight plug/1.0 mm12 ft
81040X2M10A 250V ACStraight plug/1.0 mm2 m
81040X3M10A 250V ACStraight plug/1.0 mm3 m
81040X4.5M10A 250V ACStraight plug/1.0 mm4.5 m
81040X5M10A 250V ACStraight plug/1.0 mm5 m
8107016A 250V ACStraight plug/1.5 mm2.5 m
81070X10FT16A 250V ACStraight plug/1.5 mm10 ft
81070X12FT16A 250V ACStraight plug/1.5 mm12 ft
81070X25FT16A 250V ACStraight plug/1.5 mm25 ft
81070X50FT16A 250V ACStraight plug/1.5 mm50 ft
81070X2M16A 250V ACStraight plug/1.5 mm2 m
81070X3M16A 250V ACStraight plug/1.5 mm3 m
81070X4.5M16A 250V ACStraight plug/1.5 mm4.5 m
81070X5M16A 250V ACStraight plug/1.5 mm5 m
Cordage - H05VV-F3G - CE Mark
Belgium Power Cord - Belgium plug to Unterminated End
Belgium Power Cords, Type E Plug
  FR1-16P       "CE" Mark       Unterminated

Belgium Power Cords, Power Supply Cord Sets to Unterminated Cord End
CEE 7/7, CEE 7/5, Type E Down-angle Plug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescription / ConductorsLength
815206A 250V ACDown-angle plug,
0.75 mm		2.5 m
8155010A 250V ACDown-angle plug,
1.0 mm		2.5 m
81550X10FT10A 250V ACDown-angle plug,
1.0 mm		10 ft
81550X2M10A 250V ACDown-angle plug,
1.0 mm		2 m
81550X3M10A 250V ACDown-angle plug,
1.0 mm		3 m
81550X4.5M10A 250V ACDown-angle plug,
1.0 mm		4.5 m
81550X5M10A 250V ACDown-angle plug,
1.0 mm		5 m
8158016A 250V ACDown-angle plug,
1.5 mm		2.5 m
81580X10FT16A 250V ACDown-angle plug,
1.5 mm		10 ft
81580X2M16A 250V ACDown-angle plug,
1.5 mm		2 m
81580X3M16A 250V ACDown-angle plug,
1.5 mm		3 m
81580X4.5M16A 250V ACDown-angle plug,
1.5 mm		4.5 m
81580X5M16A 250V ACDown-angle plug,
1.5 mm		5 m
Cordage - H05VV-F3G - CE Mark
Belgium Power Cord - Belgium plug to Unterminated End
Belgium Power Cords, Type E Plug
  FR1-16P       "CE" Mark       Unterminated

Belgium Power Cords, Power Supply Cord Sets to Unterminated Cord End
CEE 7/16 (Non-Polarized) Europlug,
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescription / ConductorsLength
902002.5A 250V ACStraight plug/0.75 mm
H03VV-H2-F2		1.8 m
904002.5A 250V ACStraight plug/0.75 mm
H05VV-F2		1.8 m
Belgium Power Cord - Belgium plug to Unterminated End
Belgium Power Cords, Europlug
  CEE 7/16       "CE" Mark       Unterminated
