Part Number70225-30HH
Description: EUROPEAN SCHUKO 16 AMPERE-230 VOLT CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), HORIZONTAL SURFACE MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Screw terminal torque = 0.08Nm. Operating temp. = -5°C to +40°C.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.
Certifications: RoHS, CE
Standards: CEE 7/3, DIN 49440/49441
Technical Data:
View Technical Data Drawing: 70225-30HH.pdf
Price & Avail: Contact Sales Office for Price and Delivery: Quantity Discount Incentives Available - Majority of all Products are in Stock
EUROPEAN SCHUKO 16 AMPERE-230 VOLT CEE 7/3 <font color="yellow">GFCI (RCBO/RCD)</font> OUTLET, TYPE F (EU1-16R), 50/60 Hz, <font color="yellow">(30mA TRIP)</font>, IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), HORIZONTAL SURFACE MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). GRAY.

<BR><font color="yellow">Notes:</font>
<BR><font color="yellow">**</font>  M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
<BR><font color="yellow">*</font> Downstream outlets can be protected. Use on single phase 230 volt circuits only.
<BR><font color="yellow">*</font> Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
<BR><font color="yellow">*</font> Screw terminal torque = 0.08Nm. Operating temp. = -5°C to +40°C.
<BR><font color="yellow">*</font> Weatherproof IP66 rated outlets listed below. Scroll down to view.
<BR> <font color="yellow">*</font> Not for use on life support, medical equipment, refrigeration equipment.
<BR><font color="yellow">*</font> GFCI (RCBO/RCD) outlets are available for all countries. Contact us.
Scroll down to view
Related Products
Associated Products
View & Print

product data
Associated Products
View & Print

product data
Related Products:

70225-30HH

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), HORIZONTAL SURFACE MOUNT. GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10HH

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), IP55 RATE WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), HORIZONTAL SURFACE MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10VH

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), VERTICAL SURFACE MOUNT. GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30VH

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), VERTICAL SURFACE MOUNT. GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10VG

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY), VERTICAL SURFACE MOUNT. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30VG

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) (OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY), VERTICAL SURFACE MOUNT. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10HH2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA. TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**), GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30HH2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**), GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10HG2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30HG2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10HG3

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R, 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30HG3

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R, 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10VH2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**). GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30VH2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**). GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10VG2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30VG2

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60Hz, (30mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Screw terminal torque = 0.08Nm. Operating temp. = -5°C to +40°C.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10HG

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) (EU1-16R) OUTLET, 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30HG

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) (EU1-16R) OUTLET, 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10HGD

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30HGD

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10-IT

EUROPEAN SCHUKO, ITALY, CHILE, SOUTH AMERICA GFCI (RCBO/RCD) OUTLET, 16A-230V, CEE 7/3 TYPE E, F, (EU1-16R), TYPE L, CEI 23-50 (S17) CEI 23-16 (IT1-10R/IT2-16R) (10mA TRIP), 50/60Hz, SHUTTERED CONTACTS, IP55 RATED WEATHERPROOF BOX / COVER, HORIZONTAL SURFACE MOUNT. GRAY.
Notes:
* Accepts Type E, F European CEE 7, CEE 7/4, CEE 7/7 plugs & Italy, Chile type L 10 Ampere & 16 Ampere plugs.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30-IT

EUROPEAN SCHUKO, ITALY, CHILE, SOUTH AMERICA GFCI (RCBO/RCD) OUTLET, 16A-230V, CEE 7/3 TYPE E, F, (EU1-16R), TYPE L, CEI 23-50 (S17) CEI 23-16 (IT1-10R/IT2-16R) (30mA TRIP), 50/60Hz, SHUTTERED CONTACTS, IP55 RATED WEATHERPROOF BOX / COVER, HORIZONTAL SURFACE MOUNT. GRAY.
Notes:
* Accepts Type E, F European CEE 7, CEE 7/4, CEE 7/7 plugs & Italy, Chile type L 10 Ampere & 16 Ampere plugs.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

5021-10HP

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA.TRIP), WEATHERPROOF IP55 RATED, PANEL MOUNT OR FLUSH WALL BOX MOUNT. GRAY.
Notes:
* Mating flush mount wall box #77190-D.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof surface mount IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

5021-30HP

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), WEATHERPROOF IP55 RATED, PANEL MOUNT OR FLUSH WALL BOX MOUNT. GRAY.
Notes:
* Mating flush mount wall box #77190-D.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof surface mount IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4821-10HP

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA. TRIP), PANEL MOUNT OR FLUSH BOX MOUNT. GRAY.
Notes:
* Mating flush mount wall box #77190-D.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

77190-D

EUROPEAN, INTERNATIONAL, UK, BRITISH, UNITED KINGDOM WALL BOX, FLUSH MOUNT, TWO GANG (DUPLEX), IP20 RATED (50mm DEEP), 60mm (60.3mm) MOUNTING CENTERS.
Notes:
* Mounts European, British, American, outlets on sheet rock, wall board or 1/4" paneling.
*** Mounting fins adjust out and up securing many material thicknesses ranging from 5mm to 35mm thick.
* Accepts International Modular 22.5mmX45mm & 45mmX45mm modular size devices. Call Sales Dept. for details.
* View European, British, Modular Outlets Switches & Mounting Frames, Wall Plates.[ Entire Modular Device Series ]
* Weatherproof IP55 applications require # 77190-D Wall box, # 69683X45 Mounting frame, (2) # 69580X45 covers.
* IP20 applications require # 77190-D Wall box, # 69683X45 Mounting frame, (2) # 69582X45 covers.
* Surface mount modular device wall boxes available. View part # 79235X45, # 79230X45 series.
* Flush mount steel wall boxes available, view part # 72355X47D series.
* # 77190-D Accepts # 70114-2USB outlet.
* Verify mating product(s) depth dimension for compatibility with # 77190-D wall box.
* Not for use with # 730091X45, # 730092X45 frames or 86mmX146mm size devices with 120mm (120.6mm) mounting centers.

5021-10HPD

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), WEATHERPROOF IP55 RATED, PANEL MOUNT OR FLUSH WALL BOX MOUNT, (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Mating flush mount wall box #77190-D3.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof surface mount IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4821-10HPD

EUROPEAN SCHUKO 16A-230V CEE 7/3 GFCI (RCBO/RCD) (EU1-16R) DUPLEX OUTLET, TYPE F, 50/60 Hz, (10mA TRIP), PANEL MOUNT OR FLUSH WALL BOX MOUNT. GRAY.
Notes:
* Mating flush mount wall box #77190-D3.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof surface mount IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

77190-D3

EUROPEAN, INTERNATIONAL, UK, BRITISH, UNITED KINGDOM WALL BOX, FLUSH MOUNT, THREE GANG, IP20 RATED (50mm DEEP), 60mm (60.3mm) MOUNTING CENTERS.
Notes:
* Mounts European, British, American, modular Outlets, Switches, Devices on sheet rock, wall board or 1/4" paneling.
*** Mounting fins adjust out and up securing many material thicknesses ranging from 5mm to 35mm thick.
* Accepts (3) International 45mmX45mm or (6) 22.5mmX45mm Sockets, Outlets, Switches, Devices. Call Sales Dept. for details.
* Verify mating product(s) depth dimension for compatibility with # 77190-D3 wall box.
* View European, British, Modular Outlets Switches & Mounting Frames, Wall Plates.[ Entire Modular Device Series ]
* IP55 applications require # 77190-D3 Wall box, # 69687X45 Mounting frame, (3) # 69580X45 WP covers.
* IP20 applications require # 77190-D3 Wall box, # 69687X45 Mounting frame, (3) # 69582X45 covers.

70200-WP-10MA

WEATHERPROOF IP66 RATED GFCI (RCBO/RCD) EUROPEAN (SCHUKO) OUTLET, 16A-250V, 50/60 Hz, 10mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, SURFACE MOUNT ENCLOSURE BOX (IP66 RATED (COVER CLOSED), LOCKABLE COVER (**). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
** WP cover lockable, accepts down angle plugs (not all plug variations).
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Enclosure: UV stabilized PC, Operational temp = -5°C to +40°C.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70200-WP-30MA

WEATHERPROOF IP66 RATED GFCI (RCBO/RCD) EUROPEAN (SCHUKO) OUTLET, 16A-250V, 50/60 Hz, 30mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, SURFACE MOUNT ENCLOSURE BOX (IP66 RATED (COVER CLOSED), LOCKABLE COVER (**). GRAY. LOCKABLE COVER (**). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
** WP cover lockable, Accepts down angle plugs (not all plug variations).
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Enclosure: UV stabilized PC, Operational temp = -5°C to +40°C.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70200x45

EUROPEAN (SCHUKO) GFCI (RCBO/RCD) OUTLET, 16A-250V, 50/60 Hz, 10mA TRIP, CEE 7/3 TYPE F (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, FLUSH MOUNTS ON STANDARD AMERICAN 2 GANG WALL BOX. WHITE.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, no reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70200x45-IT

EUROPEAN (SCHUKO), ITALY, CHILE, S. AMERICA GFCI (RCBO/RCD) OUTLET, 16A-230V, 50/60 Hz, 10mA TRIP, CEE 7/3 TYPE F (EU1-16R), TYPE L, (IT1-10R/IT2-16R), CEI 23-50 (S17) CEI 23-16, SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, FLUSH MOUNTS ON STANDARD AMERICAN 2 GANG WALL BOX. WHITE.
Notes:
* Accepts type E, F European CEE 7, CEE 7/4, CEE 7/7 plugs, Euro CEE plugs, Italy, Chile type L 10 Ampere / 16 Ampere plugs.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70114-RCD-LC

EUROPEAN (SCHUKO) GFCI (RCD) OUTLET, 16A-250V, 50 Hz, 10mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, ON/OFF INDICATORS, SCREWLESS TERMINALS. WHITE.
Notes:
* Mounts on European wall boxes with 60mm (60.3mm) mounting centers.
* Mounts on # wall boxes # 72350X47D, 72350X35D, 72350-F wall boxes or panel mount.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCD) outlets are available for all countries. Contact us.

70114-RCD

WEATHERPROOF IP44 RATED CLASS 1 (COVER CLOSED) GFCI (RCD) EUROPEAN (SCHUKO) OUTLET, 16A-230V, 50 Hz, 10mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, ON/OFF INDICATORS, SCREW LESS TERMINALS. WHITE.
Notes:
* Mounts on European wall boxes with 60mm (60.3mm) mounting centers.
* Mounts on # wall boxes # 72350X47D, 72350X35D, 72350-F wall boxes or panel mount.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCD) outlets are available for all countries. Contact us.

71225

FRANCE, BELGIUM GFCI (RCBO/RCD) 16 AMPERE-230 VOLT OUTLET, CEE 7/5 TYPE E (FR1-16R), 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY (**) . GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Screw terminal torque = 0.08Nm. Operating temp. = -5°C to +40°C.
* Not for use on life support, medical equipment, refrigeration equipment.
** M20 "Hub Entry" designs and IP66 rated versions available. GFCI (RCBO/RCD) outlets are available for all countries.

71225-30

FRANCE, BELGIUM GFCI GFCI (RCBO/RCD) 16 AMPERE-230 VOLT OUTLET, CEE 7/5 TYPE E (FR1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY (**) . GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Screw terminal torque = 0.08Nm. Operating temp. = -5°C to +40°C.
* Not for use on life support, medical equipment, refrigeration equipment.
** M20 "Hub Entry" designs and IP66 rated versions available. GFCI (RCBO/RCD) outlets are available for all countries.

71225-10HGD

FRANCE, BELGIUM GFCI (RCBO/RCD) 16A-230V DUPLEX OUTLET, CEE 7/5 TYPE E (FR1-16R), 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries.

71225-30HGD

FRANCE, BELGIUM GFCI (RCBO/RCD) 16A-230V DUPLEX OUTLET, CEE 7/5 TYPE E (FR1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries.

71200x45

FRANCE, BELGIUM GFCI (RCBO/RCD) OUTLET, 16A-230V, 50/60 Hz, 10mA TRIP, CEE 7/5 TYPE E (FR1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, FLUSH MOUNTS ON STANDARD AMERICAN 2 GANG WALL BOX. WHITE.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

85100-RCD

MULTI-CONFIGURATION SOUTH AMERICA, EUROPEAN, THAILAND, CHINA, ASIA, AMERICAN, INTERNATIONAL 16 AMPERE 220-250 VOLT, 6mA TRIP, DUPLEX GFCI (RCD) OUTLET, INDICATOR LIGHT, TEST/RESET BUTTONS, 2 POLE-3 WIRE GROUNDING (2P+E). WHITE.
Notes:
* Mounts on American 2x4 wall boxes & International wall boxes with 39/32" (83mm / 84mm) mounting centers.
* Surface mounts on # 74225, # 84225-AR wall boxes or panel mount. Weatherproof horizontal mount cover # 74900-MCS
* Accepts Australia, China, South America Thailand, Asia, Israel, American plugs & European plugs with (4.8mm pins / 4.0mm pins).
* For use on International, European 220-250 volt (line to neutral) single phase circuits only.
* Protects downstream outlets.
* Not for use on life support, medical equipment, refrigeration equipment.

74900-RCDS

UNIVERSAL EUROPEAN, INTERNATIONAL ASIA, THAILAND CHINA MULTI-CONFIGURATION GFCI (RCD) OUTLET, 20 AMP 250 VOLT, 6mA TRIP , TEST / RESET BUTTONS, INDICATOR LIGHT, WHITE.
Notes:
* Mounts on American 2x4 wall boxes & International wall boxes with 3.28" (83mm / 84mm) mounting centers.
* Surface mounts on # 74225, # 84225-AR wall boxes or panel mount. Weatherproof horizontal mount cover # 74900-MCS
* Accepts Australia, China, South America Thailand, Asia, Israel, American plugs & European plugs with (4.8mm pins / 4.0mm pins).
* For use on International, European 220-250 volt (line to neutral) single phase circuits only. Protects downstream outlets.
* Not for use on life support, medical equipment, refrigeration equipment.

70140-RCD30

EUROPEAN SCHUKO PLUG, CEE 7/7 GFCI RCD, 16A-230V, TYPE E, F PLUG (EU1-16P), 50Hz, 30mA TRIP, IP54 RATED, REWIREABLE ANGLE PLUG, BLACK.

70140-RCD10

EUROPEAN SCHUKO PLUG, 16A-230V (3680 WATTS), 50Hz, GFCI /RCD (PRCD-S) 10mA TRIP TYPE E, F PLUG, CEE 7/7 (EU1-16P), IP54 RATED, REWIREABLE ANGLE PLUG, BLACK.

70140-PRCD-10MA

EUROPEAN, GERMANY, FRANCE, SCHUKO PLUG ADAPTER, CEE 7/7 (EU1-16P) (FR1-16P) PORTABLE GFCI / RCD (PRCD-S) PLUG ADAPTER, 10mA TRIP, 16A-250V, 50Hz / 60Hz, TYPE E, F, (EU1-16R) POWER OUTLET, IP20 RATED, PLUG ADAPTER, BLACK. APPROVALS: GS (INTERTEK), CE MARK.
Notes:
* Operating temp. = -25°C to +40°C.
* Plug adapter connects with Germany, France, Belgium power outlets and CEE 7/3, CEE 7/5 type outlets used in other countries.
* 30mA trip version = #70140-PRCD-30MA available.
* 10mA and 30mA British, UK versions available = #72140-PRCD-10MA, #72140-PRCD-30MA.
* Requires “reset” after power failure. Not for use on freezers, refrigerators, life support equipment or equipment where power must be maintained.

70140-PRCD-30MA

EUROPEAN, GERMANY, FRANCE, SCHUKO PLUG ADAPTER, CEE /7 (EU1-16P) (FR1-16P) PORTABLE GFCI / RCD (PRCD-S) PLUG ADAPTER, 30mA TRIP, 16A-250V, 50Hz / 60Hz, TYPE E, F, (EU1-16R) POWER OUTLET, IP20 RATED, PLUG ADAPTER, BLACK. APPROVALS: GS (INTERTEK), CE MARK.
Notes:
* Operating temp. = -25°C to +40°C.
* Plug adapter connects with Germany, France, Belgium power outlets and CEE 7/3, CEE 7/5 type outlets used in other countries.
* 10mA trip version = #70140-PRCD-10MA available.
* 10mA and 30mA British, UK versions available = #72140-PRCD-10MA, #72140-PRCD-30MA.
* Requires “reset” after power failure. Not for use on freezers, refrigerators, life support equipment or equipment where power must be maintained.

36025-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 TYPE E (EU1-16P) PLUG WITH "IN-LINE" GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 TYPE F (EU1-16R) CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)
Notes:
* GFCI / RCD 30MA Trip Inline length options. Select: 6FT - 10FT - 15FT - 25FT - 50FT - 75FT - 100FT , - 10MA Trip Versions .
* GFCI / RCD Plug Versions: 36025-RCD , * Standard Versions: 36025 , * Weatherproof Versions: 36025-WP .

36025

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 CONNECTOR (EU1-16R), 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)
Notes:
* Extension cord length options. Select: 6FT - 10FT - 15FT - 25FT - 50FT - 75FT - 100FT - 150FT .
* Weatherproof Versions: 36025-WP , * GFCI / RCD Plug Versions: 36025-RCD , * GFCI / RCD Inline Versions: 36025-RCDS10 .

70170-3CS

EUROPEAN SCHUKO 16A-250V, 50/60 Hz, IP44, THREE (45° ANGLE) OUTLET POWER STRIP, IN-LINE CONNECTOR (***), CEE 7/3 TYPE F (EU1-16R), FLIP LID CLOSURE COVERS, IMPACT RESISTANT (*). BLACK.
Notes:
* (*) Elastomer rubber.
* Max cord O.D. = 10mm (0.394").
* #70170-3CS PDU horizontal rack mountable. Use #52019, #52019-BLK mounting plates.
* (***) with integral hanger bracket.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.

70170-3CA

EUROPEAN SCHUKO CONNECTOR, 16 AMPERE-250 VOLT, CEE 7/3 TYPE F (EU1-16R) THREE OUTLET, IP54 RUBBER REWIREABLE CONNECTOR (***), SNAP SHUT CLOSURE LIDS. BLACK.
Notes:
* (***) with integral hanger bracket.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.

70170-3C

EUROPEAN SCHUKO CONNECTOR, 16A-250V CEE 7/3 TYPE F (EU1-16R) THREE OUTLET SPLASHPROOF RUBBER REWIREABLE CONNECTOR (***), IP44, FLIP LID CLOSURE COVERS, T SHAPE BODY, IMPACT RESISTANT. BLACK.
Notes:
* Max cord O.D. = 15mm (0.590").
* (***) with integral hanger bracket.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.

52906-WP

EUROPEAN CEE 7/3 "SCHUKO" 6 OUTLET (EU1-16R) 16A-250V PDU POWER STRIP, WITH OUTLET COVERS, 3.0 METER (9FT-10IN) CORD. BLACK/GRAY.
Notes:
* PDU horizontal rack mount applications. Use #52019, #52019-BLK rack mounting plates.

71449

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP67 RATED WATERTIGHT LOCKING POWER STRIP, (***), CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* # 71449 Power Strip locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* # 71449 Power Strip locks onto Watertight Plug # 70341-N. Prevents accidental disconnects.
* Max cord O.D. = 18.3mm (0.720"). Terminal torque outlets = 3Nm max. Material: PA6 (Nylon) Temp. Range:-40°C to +80°C.
* (***) With integral hanger bracket.
* European Schuko Watertight Extension cords available. View # 72025.

71441

EUROPEAN SCHUKO PLUG, 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED (WATERTIGHT), CEE 7/4 TYPE E PLUG (EU1-16P), REWIREABLE LOCKING PLUG, GRAY / BLUE.
Notes:
* # 71441 Watertight Plug Locks onto Schuko Connector # 71445. Prevents accidental disconnects.
* # 71441 Watertight Plug Locks onto Schuko Connector # 70361. Prevents accidental disconnects.
* # 71441 Watertight Plug Locks onto Schuko Power Strip # 71449. Prevents accidental disconnects.
* Spare watertight IP68 rated closure covers available for # 71441. View # 71440.
* European Schuko Watertight Extension cords available. View # 72025.

71445

EUROPEAN SCHUKO CONNECTOR, 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT REWIREABLE LOCKING CONNECTOR, CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* # 71445 Watertight Connector Locks onto Schuko Plug # 71441. Prevents accidental disconnects.
* # 71445 Watertight Connector Locks onto Schuko Plug # 70341-N . Prevents accidental disconnects.
* # 71445 Watertight Connector Locks onto France / Belgium Plug, # 71341 . Prevents accidental disconnects.
* Cord grip range = 8-16mm (0.315-0.629"), Terminal torque = 3Nm max. Material: PA6 (Nylon) Temp. Range:-40°C to +80°C.
* European Schuko Watertight Extension cords available. View # 72025.

71446

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT LOCKING OUTLET, CEE 7/3 TYPE F (EU1-16R), PANEL / WALL BOX MOUNT. GRAY / BLUE.
Notes:
* # 71446 Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* # 71446 Outlet locks onto Watertight Plug # 70341-N. Prevents accidental disconnects.
* Outlet mounting centers 58mm-60mm size.
* European Schuko Watertight Extension cords available. View # 72025.

71447

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT LOCKING OUTLET CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* Includes one PG16 cable strain relief. Additional PG16 cable strain reliefs use Part # 20516-GRY.
* # 71446 Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* # 71446 Outlet locks onto Watertight Plug # 70341-N. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 72025.

20516-GRY

PG16 STRAIN RELIEF WITH LOCK NUT, LIGHT GREY.
Notes:
* Mounts in PG16 knock outs on IP68 rated wall boxes #71447, 71443. Boxes are supplied with one #20516-GRY strain relief.

71448

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT DOWN ANGLE LOCKING OUTLET, CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* Includes one PG16 cable strain relief. Additional PG16 cable strain reliefs use Part # 20516.
* # 71448 Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* # 71448 Outlet locks onto Watertight Plug # 70341-N. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 72025.

71442

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 WATERTIGHT LOCKING FLANGE MOUNT (58mm-60mm) POWER INLET WITH GASKET AND CLOSURE COVER, CEE 7/4 TYPE E (EU1-16P), PANEL MOUNT OR WALL BOX MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). NYLON. GRAY / BLUE.
Notes:
* # 71442 Watertight Power Inlet Locks onto Schuko Connector # 71445 . Prevents accidental disconnects.
* # 71442 Watertight Power Inlet Locks onto Schuko Connector # 70361. Prevents accidental disconnects.
* Spare watertight IP68 rated closure covers available for # 71442. View # 71440-A.
* European Schuko Watertight Extension cords available. View # 72025.

71443

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT LOCKING FLANGED POWER INLET, CEE 7/4 TYPE E (EU1-16P). GRAY / BLUE.
Notes:
* Includes one PG16 cable strain relief. Additional PG16 cable strain reliefs use Part # 20516-GRY.
* # 71443 Watertight Power Inlet Locks onto Schuko Connector # 71445 . Prevents accidental disconnects.
* # 71443 Watertight Power Inlet Locks onto Schuko Connector # 70361. Prevents accidental disconnects.
* Spare watertight IP68 rated closure covers available for # 71443. View # 71440-A.
* European Schuko Watertight Extension cords available. View # 72025.

71444

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT DOWN ANGLE LOCKING FLANGED POWER INLET, CEE 7/4 TYPE E (EU1-16P). GRAY / BLUE.
Notes:
* Includes one PG16 cable strain relief. Additional PG16 cable strain reliefs use Part # 20516.
* # 71444 Watertight Power Inlet Locks onto Schuko Connector # 71445 . Prevents accidental disconnects.
* # 71444 Watertight Power Inlet Locks onto Schuko Connector # 70361. Prevents accidental disconnects.
* Spare watertight IP68 rated closure covers available for # 71444. View # 71440-B.
* European Schuko Watertight Extension cords available. View # 72025.

70190

EUROPEAN CEE 7/7 (EU1-16P) SCHUKO TYPE E, F, 16A-250V WEATHERPROOF IP44 POWER INLET. BLACK.
Notes:
* # 70190 Accepts European Schuko # 70161 (EU1-16R), France / Belgium # 71161 (FR1-16R) type connectors.
* IP68 Rated Watertight option listed below.
* # 71442 , 71443 , 71444 Watertight Power Inlets Lock onto Schuko Connector # 71445 . Prevents accidental disconnects.

70395

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 WATERTIGHT LOCKING FLANGE MOUNT (60mm-60mm) POWER INLET WITH GASKET AND CLOSURE COVER, CEE 7/4 TYPE E (EU1-16P), PANEL MOUNT OR WALL BOX MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). NYLON. GRAY / BLUE.
Notes:
* 70395 Watertight Power Inlet Locks onto Schuko Connector # 70361 . Prevents accidental disconnects.
* Material = Thermoplastic Elastomer, Temperature Range: -15°C to +70°C.
* European Schuko Watertight Extension cords available. View # 70025.

70161

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE F, CEE 7/3 (EU1-16R) REWIREABLE IN-LINE CONNECTOR, MAX. CORD O.D. = 13mm (0.510"), BLACK.
Notes:
* Operating temp. = -10°C to +60°C.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

36025

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 CONNECTOR (EU1-16R), 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)
Notes:
* Extension cord length options. Select: 6FT - 10FT - 15FT - 25FT - 50FT - 75FT - 100FT - 150FT .
* Weatherproof Versions: 36025-WP , * GFCI / RCD Plug Versions: 36025-RCD , * GFCI / RCD Inline Versions: 36025-RCDS10 .

70341-N

EUROPEAN SCHUKO, GERMAN, FRANCE, BELGIUM PLUG, IP66 / IP68 WATERTIGHT, 16A-250V, CEE 7/7 (EU1-16P) TYPE E, F PLUG, REWIREABLE LOCKING PLUG, 2 POLE-3 WIRE GROUNDING (2P+E). BLUE.
Notes:
* # 70341-N Watertight Plug Locks onto Schuko Outlets / Connectors series # 70361. Prevents accidental disconnects.
* # 70341-N Watertight Plug Locks onto Schuko Watertight Power Strip # 71449. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Available in Color Dark Green. Part #70341-N-GRN

70361

EUROPEAN SCHUKO CONNECTOR, LOCKING 16A-250V IP66 / IP68 WATERTIGHT REWIREABLE CONNECTOR, CEE 7/3 (EU1-16R) TYPE E, F, SHUTTERED CONTACTS. BLUE.
Notes:
* # 70361 Watertight Connector Locks onto Schuko Plug # 70341-N . Prevents accidental disconnects.
* # 70361 Watertight Connector Locks onto Schuko Plug # 71441. Prevents accidental disconnects.
* # 70361 Watertight Connector Locks onto Schuko Power Inlet series # 71442. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Available in Color Dark Green. Part #70361-GRN

70300

EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET, PANEL OR WALL BOX MOUNT (WITH GASKET), 2 POLE-3 WIRE GROUNDING (2P+E). BLUE.
Notes:
* # 70300 Outlet locks onto Watertight Plug # 70341-N . Prevents accidental disconnects.
* # 70300 Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* # 70025 Watertight Extension cords available. View # 70025.
* Available in Color Dark Green. Part #70300-GRN

70310-NS

EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. BLUE.
Notes:
* # 70310-NS Outlet locks onto Watertight Plug # 70341-N . Prevents accidental disconnects.
* # 70310-NS Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Surface mount applications = Use # 71325,71320,71322 wall boxes listed below in related products.
* Available in Color Dark Green. Part #70310-NS-GRN

70341-N-GRN

EUROPEAN SCHUKO, GERMAN, FRANCE, BELGIUM PLUG, IP66 / IP68 WATERTIGHT, 16A-250V, CEE 7/7 (EU1-16P) TYPE E, F PLUG, REWIREABLE LOCKING PLUG, 2 POLE-3 WIRE GROUNDING (2P+E). DARK GREEN.
Notes:
* # 70341-N-GRN Watertight Plug Locks onto Schuko Outlets / Connectors series # 70361-GRN and # 70310-NS-GRN. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Available in Color Blue. Part #70341-N

70361-GRN

EUROPEAN SCHUKO CONNECTOR, LOCKING 16A-250V IP66 / IP68 WATERTIGHT REWIREABLE CONNECTOR, CEE 7/3 (EU1-16R) TYPE E, F, SHUTTERED CONTACTS. DARK GREEN.
Notes:
* # 70361-GRN Watertight Connector Locks onto Schuko Plug # 70341-N-GRN . Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Available in Color Blue. Part #70361

70300-GRN

EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET, PANEL OR WALL BOX MOUNT (WITH GASKET), 2 POLE-3 WIRE GROUNDING (2P+E). DARK GREEN.
Notes:
* # 70300-GRN Outlet locks onto Watertight Plug # 70341-N-GRN . Prevents accidental disconnects.href="https://internationalconfig.com/icc6.asp?item=70025" style="text-decoration: none"> 70025.
* Available in Color Blue. Part #70300

70310-NS-GRN

EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. DARK GREEN.
Notes:
* # 70310-NS-GRN Outlet locks onto Watertight Plug # 70341-N-GRN . Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Surface mount applications = Use # 71325,71320,71322 wall boxes listed below in related products.
* Available in Color Blue. Part #70310-NS

71325

WATERTIGHT IP66 / IP68 DOWN ANGLE SURFACE MOUNT WALL BOX. GRAY.
Notes:
Accepts #70310-NS European Schuko outlet or France / Belgium #71130 outlet.

71320

WATERTIGHT IP66, IP68 SURFACE MOUNT WALL BOX WITH M20 CABLE STRAIN RELIEF. GRAY.
Notes:
Accepts # 70310-NS European Schuko outlet or # France / Belgium # 71130 outlet.

71322

WATERTIGHT IP66, IP68 SURFACE MOUNT WALL BOX WITH (2) M20 CABLE STRAIN RELIEFS. GRAY.
Notes:
Accepts # 70310-NS European Schuko outlet or # France / Belgium # 71130 outlet.

205M20

M20 STRAIN RELIEF WITH LOCK NUT, LIGHT GREY.
DIAMETER RANGE = 6.0-12.0mm.

205M20-BLK

M20 STRAIN RELIEF WITH LOCK NUT, BLACK.
DIAMETER RANGE = 6.0-12.0mm.

70125

WEATHERPROOF IP44, IP54 RATED SURFACE MOUNT WALL BOX FOR PANEL MOUNT OUTLETS. BLACK.
Notes:
* Din rail mountable, use #70125-DIN bracket.
* Gaskets provided with mating outlets.

70120

EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. GRAY FLIP LID, GRAY BASE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-BLK

EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-BLK-GC

EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. BLACK BASE, GRAY FLIP LID COVER.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54

EUROPEAN SCHUKO CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. GRAY.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54BLK

EUROPE, EUROPEAN SCHUKO CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-BLU

EUROPEAN SCHUKO CEE 7/3 (EU1-16R) 16A-250V WEATHERPROOF OUTLET, SHUTTERED CONTACTS, PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54BLU

EUROPE, EUROPEAN SCHUKO CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-RED

EUROPEAN SCHUKO CEE 7/3 (EU1-16R) 16A-250V WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. RED.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54RED

EUROPE, EUROPEAN SCHUKO CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. BLACK WITH RED COVER.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70114-2G

EUROPEAN SCHUKO 16A-250V DUPLEX OUTLET, CEE 7/3 TYPE E, F (EU1-16R), SHUTTERED CONTACTS, 86mmX146mm SIZE, FLUSH MOUNT OR PANEL MOUNT. WHITE.
Notes:
* European wall boxes = #72355X47D, 72355X35D, 72355-F, 72365.
* Weatherproof versions available. Use #74790-B2 (IP66 rated), #74790-DX (IP54 rated).
* American 2x4 wall box mount applications = view outlet #70114-DW.

74790-B2

WEATHERPROOF SURFACE MOUNT IP66 RATED (COVER CLOSED**) DUPLEX OUTLET ENCLOSURE, IMPACT RESISTANT.
Notes:
* Enclosure accepts #72300-DS-10mA GFCI / RCD Duplex Outlet.
* Weatherproof cover 74790-B2 designed to maintain IP66 protection rating while in use.
* Enclosure accepts (86mmX146mm size) British, UK, European, International sockets, switches with 120mm (120.6mm) mounting centers.
* Enclosure accepts modular outlets, switches. Requires # 730093X45, or # 730094X45 mounting frame / wall plate.
** Cover can be closed & locked over down angle plugs (not all angle plug variations).
* M20 knockout type cable entries [expandable to M25] - 8 places [top, bottom, sides].
* M20 cutout type cable entry [expandable to M25] - 1 place [back].
* Material = UV stabilized PC, Temp. rating = -5°C to +40°C.
* Mating receptacles, sockets, outlets are listed below in related products. Scroll down to view.

74790-DX

WEATHERPROOF DUPLEX OUTLET COVER, IP54 RATED (COVER CLOSED), (IP20 COVER OPEN), GASKET INCLUDED, IMPACT RESISTANCE. CLEAR.
Notes:
* Cover accepts (86mmX146mm size) British BS1363 outlets, mounts on wall boxes with 120mm (120mm.6) centers.
* Cover also accepts modular outlets, circuit breakers, switches. Requires # 730093X45 or # 730094X45 mounting frame.
* View modular component options here. Modular Devices Link
* Weatherproof cover 74790-DK designed to maintain IP54 protection rating while in use.
* 74790-DX accepts GFCI / RCD duplex outlet # 72300-DS-10MA. IP20 rated while in use. (cover open).
* Note: Cover has internal & external cord grip strain relief design. Secures power cords.

70114-1G

EUROPEAN SCHUKO 16A-250V OUTLET, CEE 7/3 TYPE F (EU1-16R), SHUTTERED CONTACTS, (86mmX86mm SIZE), FLUSH MOUNT OR PANEL MOUNT. WHITE.
Notes:
* Mounts on European wall boxes with 60mm (60.3mm) centers.
* European wall boxes = #72350X47D, 72350X35D, 72350-F, 77190, 72360.
* Weatherproof versions available. Use #74790-B1 (IP66 rated), #74790-A (IP55 rated), #74790 (IP13 rated).

74790-B1

WEATHERPROOF SURFACE MOUNT IP 66 RATED (COVER CLOSED**) ENCLOSURE, IMPACT RESISTANT. GRAY.
Notes:
* Enclosure accepts #72300-S-10mA GFCI / RCD Outlet.
* Weatherproof cover 74790-B1 designed to maintain IP66 protection rating while in use.
* Enclosure accepts (86mmX86mm size) British, UK, European, International sockets, switches with 60mm (60.3mm) mounting centers.
* Enclosure accepts modular outlets, switches. Requires # 730092X45, or # 730091X45 mounting frame / wall plate.
** Cover can be closed & locked over down angle plugs (not all angle plug variations).

74790-A

WEATHERPROOF ONE GANG LOCKABLE COVER, IP55 RATED (COVER CLOSED). CLEAR.
Notes:
Notes:
* Cover accepts British, UK, European, International sockets, outlets, switches (86mmX86mm size) with 60mm (60.3mm) mounting centers.
* Cover accepts Modular British, European, International outlets, switches. Requires wall plate / frame #730092X45, #730091X45.
* Cover accepts down angle plugs (Not all plug variations).

70141-HD

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, 16A-250V, (4.8mm DIA. PINS), TYPE E, F PLUG CEE 7/7 (EU1-16P), IP54, REWIREABLE PLUG, IMPACT RESISTANT, MAX. CORD O.D. = 0.433". BLACK.
Notes:
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70150

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, 16A-250V CEE 7/7, TYPE E, F PLUG (EU1-16P), (4.8mm DIA. PINS), REWIREABLE RUBBER PLUG, MAX. CORD O.D.= 0.433" DIA., BLACK.
Notes:
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70150-DA

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, 16 AMPERE-250 VOLT CEE 7/7, VDE DIN 0620 TYPE E, F DOWN ANGLE PLUG (EU1-16P), (4.8mm DIA. PINS), REWIREABLE RUBBER PLUG, 2 POLE-3 WIRE GROUNDING (2P+E), IP44, IK08 RATED, IMPACT RESISTANT, MAX. CORD O.D.= 0.433" DIA., BLACK.
Notes:
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70150-A

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, 16A-250V, 4.8 mm DIA. PINS, TYPE E, F PLUG, CEE 7/7 (EU1-16P), IP44, IMPACT RESISTANT, REWIREABLE RUBBER PLUG, MAX. CORD O.D. = 8.0mm (0.315"), BLACK.
Notes:
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70150-N

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, 16A-250V TYPE E, F PLUG, CEE 7/7, CEE 7/4 PLUG (4.8mm DIA. PINS) (EU1-16P), IP54 RATED, REWIREABLE PLUG, O.D. CORD GRIP = 12.4mm (0.473"), BLACK.
Notes:
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70151

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, (EU1-16P) 16A-250V CEE 7/7, DIN / VDE 0620, IEC 60884 TYPE E, F PLUG, 4.8 mm DIA. PINS, IP44 RATED, IK08 RATED, REWIREABLE ELAMID PLASTIC PLUG, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., BLACK.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70151-BLU

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, (EU1-16P) 16A-250V CEE 7/7, DIN / VDE 0620, IEC 60884 TYPE E, F PLUG, 4.8 mm DIA. PINS, IP44 RATED, IK08 RATED, REWIREABLE ELAMID PLASTIC PLUG, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., BLUE.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70151-RD

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM PLUG, (EU1-16P) 16A-250V CEE 7/7, DIN / VDE 0620, IEC 60884 TYPE E, F PLUG, 4.8 mm DIA. PINS, IP44 RATED, IK08 RATED, REWIREABLE ELAMID PLASTIC PLUG, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., RED.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70141

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM, RUSSIA PLUG, 16A-250V, CEE 7/7 (EU1-16P) TYPE E, F PLUG (4.8mm DIA. PINS), IP20 RATED, REWIREABLE PLUG, O.D. CORD GRIP = 10.4mm (0.409") DIA., BLACK.
Notes:
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70130-NSB

EUROPEAN SCHUKO PLUG, 16A-250V, IP20, CEE 7/7 TYPE E, F PLUG (EU1-16P), 4.8mm DIA. PINS, REWIREABLE DOWN ANGLE PLUG, 2 POLE-3 WIRE GROUNDING (2P+E), MAX. CORD O.D. = 10mm (0.394", NYLON. BLACK.
Notes:
* Watertight IP68/IP66 Locking plug available # 70341-N. Locking design also prevents accidental disconnect.

70161-HD

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE F, CEE 7/3 (EU1-16R) REWIREABLE IN-LINE CONNECTOR, MAX. CORD O.D. = 0.433". BLACK.
Notes:
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70161-HDA

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE F, CEE 7/3 (EU1-16R) REWIREABLE IN-LINE CONNECTOR, IP44, SNAP SHUT COVER, MAX. CORD O.D. = 0.433". BLACK.
Notes:
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70161-HDB

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE F, CEE 7/3 (EU1-16R) REWIREABLE IN-LINE CONNECTOR, IP44, FLIP LID CLOSURE COVER, MAX. CORD O.D. = 0.433". BLACK.
Notes:
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70170-N

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE F REWIREABLE CONNECTOR, CEE 7/3 (EU1-16R), IP54 RATED, CLOSURE LID, POWER ON INDICATOR, HIGH IMPACT RESISTANT BODY, MAX. CORD O.D. = 15mm (0.590") DIA., BLACK.
Notes:
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70170

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE F, CEE 7/3 (EU1-16R) SPLASHPROOF IP44 REWIREABLE IN-LINE RUBBER CONNECTOR. MAX. CORD O.D. = 12mm (0.472") DIA., BLACK.
Notes:
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70161

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE F, CEE 7/3 (EU1-16R) REWIREABLE IN-LINE CONNECTOR, MAX. CORD O.D. = 13mm (0.510"), BLACK.
Notes:
* Operating temp. = -10°C to +60°C.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70161-A

EUROPEAN SCHUKO CONNECTOR, 16A-250V TYPE E, F CEE 7/3 (EU1-16R) REWIREABLE IN-LINE CONNECTOR, MAX. CORD O.D. = 12mm (0.472"). BLACK.
Notes:
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70162

EUROPEAN SCHUKO, GERMANY CONNECTOR, (EU1-16R) 16A-250V CEE 7/3, DIN / VDE 0620, IEC 60884 TYPE F, REWIREABLE ELAMID PLASTIC CONNECTOR, IP20 RATED, SHUTTERED CONTACTS, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., BLACK.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70162-WP

EUROPEAN SCHUKO, GERMANY CONNECTOR, (EU1-16R) 16 AMPERE-250 VOLT CEE 7/3, DIN / VDE 0620, IEC 60884 TYPE F, REWIREABLE ELAMID PLASTIC CONNECTOR, PROTECTIVE FLIP LID COVER, IP44 RATED, IK08 RATED, MAX. CORD O.D. = 0.492" DIA., BLACK.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70162-BLU

EUROPEAN SCHUKO, GERMANY CONNECTOR, (EU1-16R) 16A-250V CEE 7/3, DIN / VDE 0620, IEC 60884 TYPE F, REWIREABLE ELAMID PLASTIC CONNECTOR, IP20 RATED, SHUTTERED CONTACTS, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., BLUE.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70162-WP-BLU

EUROPEAN SCHUKO, GERMANY CONNECTOR, (EU1-16R) 16 AMPERE-250 VOLT CEE 7/3, DIN / VDE 0620, IEC 60884 TYPE F, REWIREABLE ELAMID PLASTIC CONNECTOR, PROTECTIVE FLIP LID COVER, IP44 RATED, IK08 RATED, MAX. CORD O.D. = 0.492" DIA., BLUE.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70162-RD

EUROPEAN SCHUKO, GERMANY CONNECTOR, (EU1-16R) 16A-250V CEE 7/3, DIN / VDE 0620, IEC 60884 TYPE F, REWIREABLE ELAMID PLASTIC CONNECTOR, IP20 RATED, SHUTTERED CONTACTS, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., RED.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.

70162-WP-RD

EUROPEAN SCHUKO, GERMANY CONNECTOR, (EU1-16R) 16 AMPERE-250 VOLT CEE 7/3, DIN / VDE 0620, IEC 60884 TYPE F, REWIREABLE ELAMID PLASTIC CONNECTOR, PROTECTIVE FLIP LID COVER, IP44 RATED, IK08 RATED, MAX. CORD O.D. = 0.492" DIA., RED.
Notes:
*ELAMID Plastic Material Features: -40°C to +80°C rated, UV protection, chemical and impact resistant.
* European, Schuko Extension Cords, Type E, F, Weatherproof IP44, GFCI/RCD versions. View: European-Extension-Cords.
* Watertight IP68/IP66 Locking Connector available # 70361. Locking design also prevents accidental disconnect.
