Part Number70114-1G
Description: EUROPEAN "SCHUKO" 16 AMPERE-250 VOLT OUTLET, CEE 7/3 TYPE F (EU1-16R), SHUTTERED CONTACTS, (86mmX86mm SIZE), FLUSH MOUNT OR PANEL MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). WHITE.
Notes:
* Mounts on European wall boxes with 60mm (60.3mm) centers.
* European wall boxes = #72350X47D, 72350X35D, 72350-F, 77190, 72360.
* Weatherproof versions available. Use #74790-B1 (IP66 rated), #74790-A (IP55 rated), #74790 (IP13 rated).
* European "Schuko" connectors, plugs, inlets, outlets, GFCI/RCD sockets, power strips, power cords, plug adapters in related products. Scroll down to view.
Certifications: CE
Standards: CEE 7/3, DIN 49440
Data Sheet:
View Dimensional Data Sheet: 70114-1G.pdf
Price & Avail: Contact Sales Office for Price and Delivery: Quantity Discount Incentives Available - Majority of all Products are in Stock
EUROPEAN "SCHUKO" 16 AMPERE-250 VOLT OUTLET, CEE 7/3 TYPE F (EU1-16R), SHUTTERED CONTACTS, (86mmX86mm SIZE), FLUSH MOUNT OR PANEL MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). WHITE.

<BR><font color="yellow">Notes:</font>
<br><font color="yellow">*</font> Mounts on European wall boxes with 60mm (60.3mm) centers.
<BR><font color="yellow">*</font> European wall boxes = #72350X47D, 72350X35D, 72350-F, 77190, 72360.
<BR><font color="yellow">*</font> Weatherproof versions available. Use #74790-B1 (IP66 rated), #74790-A (IP55 rated), #74790 (IP13 rated).
<BR><font color="yellow">*</font> European "Schuko" connectors, plugs, inlets, outlets, GFCI/RCD sockets, power strips, power cords, plug adapters in related products. Scroll down to view.
Scroll down to view
Related Products
Associated Products # 1
View / Print

product data
Associated Products # 2
View / Print

product data
Related Products:

70114-1G

EUROPEAN "SCHUKO" 16A-250V OUTLET, CEE 7/3 TYPE F (EU1-16R), SHUTTERED CONTACTS, (86mmX86mm SIZE), FLUSH MOUNT OR PANEL MOUNT. WHITE.
Notes:
* Mounts on European wall boxes with 60mm (60.3mm) centers.
* European wall boxes = #72350X47D, 72350X35D, 72350-F, 77190, 72360.
* Weatherproof versions available. Use #74790-B1 (IP66 rated), #74790-A (IP55 rated), #74790 (IP13 rated).

72214

EUROPEAN, BRITISH BLANK ONE GANG WALL PLATE (86mmX86mm SIZE), SCREW MOUNT, MOUNTING SCREWS INCLUDED. WHITE.
Notes:
* Switch mounts on European, British wall boxes with 60mm (60.3mm) centers.
* View # 72350X47D, 72350X35D, 72350X25D, 72350-F, 72360, 72360-RED wall box series. Not for use with # 77190 wall box.
* Weatherproof cover available, IP55 rated # 74790-A.

74790-B1

WEATHERPROOF SURFACE MOUNT IP 66 RATED (COVER CLOSED**) ENCLOSURE, IMPACT RESISTANT. GRAY.
Notes:
* Enclosure accepts #72300-S-10mA GFCI / RCD Outlet.
* Weatherproof cover 74790-B1 designed to maintain IP66 protection rating while in use.
* Enclosure accepts (86mmX86mm size) British, UK, European, International sockets, switches with 60mm (60.3mm) mounting centers.
* Enclosure accepts modular outlets, switches. Requires # 730092X45, or # 730091X45 mounting frame / wall plate.
** Cover can be closed & locked over down angle plugs (not all angle plug variations).

74790-A

WEATHERPROOF ONE GANG LOCKABLE COVER, IP55 RATED (COVER CLOSED). CLEAR.
Notes:
Notes:
* Cover accepts British, UK, European, International sockets, outlets, switches (86mmX86mm size) with 60mm (60.3mm) mounting centers.
* Cover accepts Modular British, European, International outlets, switches. Requires wall plate / frame #730092X45, #730091X45.
* Cover accepts down angle plugs (Not all plug variations).

74790

WEATHER RESISTANT ONE GANG COVER, IP13 RATED (COVER CLOSED) , IMPACT RESISTANCE. WHITE.
Notes:
* Cover accepts British, UK, European, International sockets, outlets, switches (86mmX86mm size) with 60mm (60.3mm) mounting centers.
* Cover accepts modular British, European, International outlets, switches. Requires wall plate / frame #730092X45, #730091X45.
* Cover accepts down angle plugs (Not all plug variations).

70114-2G

EUROPEAN "SCHUKO" 16A-250V DUPLEX OUTLET, CEE 7/3 TYPE E, F (EU1-16R), SHUTTERED CONTACTS, 86mmX146mm SIZE, FLUSH MOUNT OR PANEL MOUNT. WHITE.
Notes:
* European wall boxes = #72355X47D, 72355X35D, 72355-F, 72365.
* Weatherproof versions available. Use #74790-B2 (IP66 rated), #74790-DX (IP54 rated).
* American 2x4 wall box mount applications = view outlet #70114-DW.

72315

EUROPEAN, BRITISH, INTERNATIONAL BLANK TWO GANG WALL PLATE, 86mmX146mm SIZE, SCREW MOUNT,
120mm (120.6mm) MOUNTING CENTERS, MOUNTING SCREWS INCLUDED, WHITE.
Notes:
* MOUNTS ON EUROPEAN FLUSH WALL BOXES #72355X25D, 72355X35D, 72355X47D, 72355-F.
* MOUNTS ON SURFACE WALL BOXES #72365, 72365-RED.
* MOUNTS ON RECESSED, SURFACE AND WEATHERPROOF BOXES WITH 120mm (120.6mm) MOUNTING CENTERS.

74790-B2

WEATHERPROOF SURFACE MOUNT IP66 RATED (COVER CLOSED**) DUPLEX OUTLET ENCLOSURE, IMPACT RESISTANT.
Notes:
* Enclosure accepts #72300-DS-10mA GFCI / RCD Duplex Outlet.
* Weatherproof cover 74790-B2 designed to maintain IP66 protection rating while in use.
* Enclosure accepts (86mmX146mm size) British, UK, European, International sockets, switches with 120mm (120.6mm) mounting centers.
* Enclosure accepts modular outlets, switches. Requires # 730093X45, or # 730094X45 mounting frame / wall plate.
** Cover can be closed & locked over down angle plugs (not all angle plug variations).
* M20 knockout type cable entries [expandable to M25] - 8 places [top, bottom, sides].
* M20 cutout type cable entry [expandable to M25] - 1 place [back].
* Material = UV stabilized PC, Temp. rating = -5C to +40C.
* Mating receptacles, sockets, outlets are listed below in related products. Scroll down to view.

74790-DX

WEATHERPROOF DUPLEX OUTLET COVER, IP54 RATED (COVER CLOSED), (IP20 COVER OPEN), GASKET INCLUDED, IMPACT RESISTANCE. CLEAR.
Notes:
* Cover accepts (86mmX146mm size) British BS1363 outlets, mounts on wall boxes with 120mm (120mm.6) centers.
* Cover also accepts modular outlets, circuit breakers, switches. Requires # 730093X45 or # 730094X45 mounting frame.
* View modular component options here. Modular Devices Link
* Weatherproof cover 74790-DK designed to maintain IP54 protection rating while in use.
* 74790-DX accepts GFCI / RCD duplex outlet # 72300-DS-10MA. IP20 rated while in use. (cover open).
* Note: Cover has internal & external cord grip strain relief design. Secures power cords.

70200-WP-10MA

WEATHERPROOF IP66 RATED GFCI (RCBO/RCD) EUROPEAN (SCHUKO) OUTLET, 16A-250V, 50/60 Hz, 10mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, SURFACE MOUNT ENCLOSURE BOX (IP66 RATED (COVER CLOSED), LOCKABLE COVER (**). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
** WP cover lockable, accepts down angle plugs (not all plug variations).
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Enclosure: UV stabilized PC, Operational temp = -5C to +40C.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70200-WP-30MA

WEATHERPROOF IP66 RATED GFCI (RCBO/RCD) EUROPEAN (SCHUKO) OUTLET, 16A-250V, 50/60 Hz, 30mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, SURFACE MOUNT ENCLOSURE BOX (IP66 RATED (COVER CLOSED), LOCKABLE COVER (**). GRAY. LOCKABLE COVER (**). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
** WP cover lockable, Accepts down angle plugs (not all plug variations).
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Enclosure: UV stabilized PC, Operational temp = -5C to +40C.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70200x45

EUROPEAN (SCHUKO) GFCI (RCBO/RCD) OUTLET, 16A-250V, 50/60 Hz, 10mA TRIP, CEE 7/3 TYPE F (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, FLUSH MOUNTS ON STANDARD AMERICAN 2 GANG WALL BOX. WHITE.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, no reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70200x45-IT

EUROPEAN (SCHUKO), ITALY, CHILE, S. AMERICA GFCI (RCBO/RCD) OUTLET, 16A-230V, 50/60 Hz, 10mA TRIP, CEE 7/3 TYPE F (EU1-16R), TYPE L, (IT1-10R/IT2-16R), CEI 23-50 (S17) CEI 23-16, SHUTTERED CONTACTS, TEST / RESET BUTTON, INDICATOR LIGHT, FLUSH MOUNTS ON STANDARD AMERICAN 2 GANG WALL BOX. WHITE.
Notes:
* Accepts type E, F European CEE 7, CEE 7/4, CEE 7/7 plugs, Euro CEE plugs, Italy, Chile type L 10 Ampere / 16 Ampere plugs.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70114-RCD-LC

EUROPEAN (SCHUKO) GFCI (RCD) OUTLET, 16A-250V, 50 Hz, 10mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, ON/OFF INDICATORS, SCREWLESS TERMINALS. WHITE.
Notes:
* Mounts on European wall boxes with 60mm (60.3mm) mounting centers.
* Mounts on # wall boxes # 72350X47D, 72350X35D, 72350-F wall boxes or panel mount.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCD) outlets are available for all countries. Contact us.

70114-RCD

WEATHERPROOF IP44 RATED CLASS 1 (COVER CLOSED) GFCI (RCD) EUROPEAN (SCHUKO) OUTLET, 16A-230V, 50 Hz, 10mA TRIP, CEE 7/3 TYPE F SOCKET (EU1-16R), SHUTTERED CONTACTS, TEST / RESET BUTTON, ON/OFF INDICATORS, SCREW LESS TERMINALS. WHITE.
Notes:
* Mounts on European wall boxes with 60mm (60.3mm) mounting centers.
* Mounts on # wall boxes # 72350X47D, 72350X35D, 72350-F wall boxes or panel mount.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCD) outlets are available for all countries. Contact us.

70225-10HG

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) (EU1-16R) OUTLET, 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30HG

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) (EU1-16R) OUTLET, 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10HGD

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30HGD

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY). GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10HH

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), IP55 RATE WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), HORIZONTAL SURFACE MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30HH

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), HORIZONTAL SURFACE MOUNT. GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10VH

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), VERTICAL SURFACE MOUNT. GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30VH

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER, M20 CABLE ENTRY HUBS (**), VERTICAL SURFACE MOUNT. GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10VG

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY), VERTICAL SURFACE MOUNT. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30VG

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) (OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), IP55 RATED WEATHERPROOF BOX AND COVER (GLAND TYPE CABLE ENTRY), VERTICAL SURFACE MOUNT. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10HG2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30HG2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10HG3

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R, 50/60 Hz, (10mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30HG3

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) DUPLEX OUTLET, TYPE F (EU1-16R, 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10VG2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30VG2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60Hz, (30mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, GLAND CABLE ENTRY. GRAY.
Notes:
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Screw terminal torque = 0.08Nm. Operating temp. = -5C to +40C.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10HH2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA. TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**), GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30HH2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), HORIZONTAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**), GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-10VH2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**). GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4721-30VH2

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), VERTICAL SURFACE MOUNT, IP20 RATED, M20 CABLE ENTRY HUBS (**). GRAY.
Notes:
** M20 adapter #01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

5021-10HP

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA.TRIP), WEATHERPROOF IP55 RATED, PANEL MOUNT OR FLUSH WALL BOX MOUNT. GRAY.
Notes:
* Mating flush mount wall box #77190-D.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof surface mount IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

5021-30HP

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (30mA TRIP), WEATHERPROOF IP55 RATED, PANEL MOUNT OR FLUSH WALL BOX MOUNT. GRAY.
Notes:
* Mating flush mount wall box #77190-D.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof surface mount IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

4821-10HP

EUROPEAN "SCHUKO" 16A-230V CEE 7/3 GFCI (RCBO/RCD) OUTLET, TYPE F (EU1-16R), 50/60 Hz, (10mA. TRIP), PANEL MOUNT OR FLUSH BOX MOUNT. GRAY.
Notes:
* Mating flush mount wall box #77190-D.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66, IP55 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-10-IT

EUROPEAN SCHUKO, ITALY, CHILE, SOUTH AMERICA GFCI (RCBO/RCD) OUTLET, 16A-230V, CEE 7/3 TYPE E, F, (EU1-16R), TYPE L, CEI 23-50 (S17) CEI 23-16 (IT1-10R/IT2-16R) (10mA TRIP), 50/60Hz, SHUTTERED CONTACTS, IP55 RATED WEATHERPROOF BOX / COVER, HORIZONTAL SURFACE MOUNT. GRAY.
Notes:
* Accepts Type E, F European CEE 7, CEE 7/4, CEE 7/7 plugs & Italy, Chile type L 10 Ampere & 16 Ampere plugs.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70225-30-IT

EUROPEAN SCHUKO, ITALY, CHILE, SOUTH AMERICA GFCI (RCBO/RCD) OUTLET, 16A-230V, CEE 7/3 TYPE E, F, (EU1-16R), TYPE L, CEI 23-50 (S17) CEI 23-16 (IT1-10R/IT2-16R) (30mA TRIP), 50/60Hz, SHUTTERED CONTACTS, IP55 RATED WEATHERPROOF BOX / COVER, HORIZONTAL SURFACE MOUNT. GRAY.
Notes:
* Accepts Type E, F European CEE 7, CEE 7/4, CEE 7/7 plugs & Italy, Chile type L 10 Ampere & 16 Ampere plugs.
* Downstream outlets can be protected. Use on single phase 230 volt circuits only.
* Latched RCD, No reset after power failure. RCBO (single pole + neutral) provides over current protection.
* Weatherproof IP66 rated outlets listed below. Scroll down to view.
* Not for use on life support, medical equipment, refrigeration equipment.
* GFCI (RCBO/RCD) outlets are available for all countries. Contact us.

70310-SM

EUROPEAN SCHUKO LOCKING (*) 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET, SURFACE MOUNT, (**) TWO M20 STRAIN RELIEFS, BLUE.
Notes:
* (*) Locking and watertight when connected with # 71441, # 70341-N, # 71341 plugs. Prevents accidental disconnects.
* Material PTB: Operating temp. = -30C to +40C. Storage temp. = -40C to +80C.
* Terminals accept 0.75mm-1.5mm conductors. Screw torques: Terminals = 0.5Nm, Housing = 0.8Nm.
* (**) IP55 rated M20 thread adapter # 01614 available. Converts M20 to 1/2 inch National Pipe Thread (NPT).

70310-NS

EUROPEAN SCHUKO LOCKING (*) 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* Panel mount or mount on European, British wall boxes with 60mm (60.3mm) centers.
* (*) Locking and watertight when connected with # 70341-N, # 71341, # 71441 plugs. Twist type locking collar locks and seals connection. Prevents accidental disconnects.

70300

EUROPEAN SCHUKO LOCKING (*) 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET, PANEL OR WALL BOX MOUNT (WITH GASKET), 2 POLE-3 WIRE GROUNDING (2P+E). BLUE.
Notes:
* (*) Locking and watertight when connected with #70341-N, #71341, #71441 Plugs. Twist type locking collar locks and seals connection. Prevents accidental disconnects.

70300-A

EUROPEAN SCHUKO LOCKING (*) 16 AMPERE-250 VOLT CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR WALL BOX MOUNT, SHUTTERED CONTACTS, 2 POLE-3 WIRE GROUNDING (2P+E). BLUE.
Notes:
* (*) Locking and watertight when connected with #70341-N, #71341, #71441 Plugs. Twist type locking collar locks and seals connection. Prevents accidental disconnects.

70341-N

EUROPEAN SCHUKO, GERMAN, FRANCE, BELGIUM LOCKING (*) 16 AMPERE-250 VOLT CEE 7/7 (EU1-16P) TYPE F, IP66 / IP68 WATERTIGHT PLUG. BLUE.
Notes:
* (*) Locking and watertight when mated with # 70361 connector, # 70300, # 70300-A, # 70310, # 70310-NS, # 70310-SM outlets. Twist type locking collar locks and seals connection. Prevents accidental disconnects.
* (*) Locking and watertight when mated with # 71445 connector, # 71446, # 71447, # 71448, # 71449 outlets. Twist type locking collar locks and seals connection.

70361

EUROPEAN SCHUKO LOCKING (*) 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT IN-LINE CONNECTOR. BLUE.
Notes:
* (*) Locking and watertight when connected with # 71442, 71443, 71444 power inlets or 71441, 70341-N, 71341 power plugs.
* Twist type locking collar locks / seals connection. Prevents accidental disconnects.

70395

# 70395 DISCONTINUED. {NEW DESIGN # 71442}
Note. View New Design IP68 rated watertight power inlets # 71442, 71443, 71444.
* # 71442 Mounting centers= 48mm-60mm.

* New Design {Gray/Blue Color} Watertight IP68 Rated Devices # 71442,71443,71444,71441,71440,71445,71446,71447,71448 listed below.

* Option: {Blue Color} Watertight IP 68 Rated versions # 70361,70341-N,70300,70300-A,70310,70310-NS,70310-SM listed below.
Note. {Blue Color} series & {Cray/Blue Color} series are interchangeable.

70325

DISCONTINUED ITEM.
NEW DESIGNS AVAILABLE. CALL FOR DETAILS.

70325A

DISCONTINUED ITEM.
NEW DESIGNS AVAILABLE. CALL FOR DETAILS.

71325

WATERTIGHT IP66 / IP68 DOWN ANGLE SURFACE MOUNT WALL BOX (*). ACCEPTS SCHUKO OUTLET # 70310-NS AND FRANCE / BELGIUM OUTLET # 71130.
Notes:
* Not for use with #70310.
* Not for use with with (*) # 71442, # 71446. View down angle versions with surface mount boxes # 71444, # 71448.

71446

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT LOCKING (**) OUTLET, CEE 7/3 TYPE F (EU1-16R), PANEL / WALL BOX MOUNT. GRAY / BLUE.
Notes:
* Material: PA6 (Nylon) Temp. Range:-40C to +80C.
* Outlet mounting centers 58mm-60mm size.
* Terminal torque = 3Nm max.
* Wall box mount. View # 70310-SM,
* (**) Locks onto plugs # 71441, # 70341-N, # 71341. Twist type locking collar seals connection. Prevents accidental disconnects.

71447

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT LOCKING OUTLET (**), CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* Terminal torque = 3Nm max.
* Material: PA6 (Nylon) Temp. Range:-40C to +80C.
* (**) Locks onto plugs # 71441, # 70341-N, # 71341. Twist type locking collar seals connection. Prevents accidental disconnects.

71448

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT DOWN ANGLE LOCKING OUTLET (**), CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* Max cord O.D. = 14.5mm (0.570")
* Terminal torque = 3Nm max.
* Material PA6 (Nylon) Temp. Range:-40C to +80C.
* (**) Locks onto plugs # 71441, # 70341-N, # 71341. Twist type locking collar seals connection. Prevents accidental disconnects.

71449

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP67 RATED WATERTIGHT THREE OUTLET LOCKING (**) POWER STRIP, IN-LINE CONNECTOR (***), CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* Max cord O.D. = 18.3mm (0.720")
* Terminal torque outlets = 3Nm max.
* Material: PA6 (Nylon) Temp. Range:-40C to +80C.
* (**) Outlets lock onto # 71441, # 70341-N, # 71341 plugs. Twist type locking cover locks / seals connection.
* (***) With integral hanger bracket.

71441

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT LOCKING PLUG (**), WITH CLOSURE COVER CEE 7/4 TYPE F (EU1-16P), GRAY / BLUE.
Notes:
* Cord grip range = 8-16mm (0.315-0.629"), Terminal torque = 3Nm max.
* Material: PA6 (Nylon) Temp. Range:-40C to +80C.
* (**) Plug locks onto # 71445 connector, # 71446, 71447, 71448, 71449 outlets. Twist type locking collar locks / seals connection.
* (**) Plug locks onto # 70361 connector, # 70300, 70310, 70310-NS, 70310-SM outlets. Twist type locking collar seals connection.
* Closure cover protects plug from weather / impact damage. Spare cover # 71440 available.

71445

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT LOCKING CONNECTOR (**), CEE 7/3 TYPE F (EU1-16R). GRAY / BLUE.
Notes:
* Cord grip range = 8-16mm (0.315-0.629"), Terminal torque = 3Nm max.
* Material: PA6 (Nylon) Temp. Range:-40C to +80C.
* (**) Locking and watertight when connected to # 71442, 71443, 71444, power inlets and # 71441, 70341-N 71341 power plugs.
* Twist type locking collar locks / seals connection. Prevents accidental disconnects.

71442

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT LOCKING (**) FLANGED INLET WITH CLOSURE COVER, CEE 7/4 TYPE F (EU1-16P), PANEL MOUNT OR WALL BOX MOUNT. NYLON. GRAY / BLUE.
Notes:
* Inlet mounting centers 58mm-60mm size.
* Material: PA6 (Nylon) Temp. Range:-40C to +80C.
* (**) Inlet locks onto # 71445, # 70361 power connectors. Twist type locking collar locks and seals connection.
* Closure cover protects inlet from weather / impact damage. Spare cover # 71440-A available.

71443

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT LOCKING FLANGED INLET (**) WITH CLOSURE COVER , CEE 7/4 TYPE F (EU1-16P). GRAY / BLUE.
Notes:
* Material: PA6 (Nylon) Temp. Range:-40C to +80C
* (**) Inlet locks onto # 71445, # 70361 power connectors. Twist type locking collar locks and seals connection. Prevents accidental disconnects.
* Closure cover protects inlet from weather / impact damage. Spare cover # 71440-A available.

71444

EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 RATED WATERTIGHT SURFACE MOUNT DOWN ANGLE LOCKING FLANGED INLET (**) WITH CLOSURE COVER , CEE 7/4 TYPE F (EU1-16P). GRAY / BLUE.
Notes:
* Max cord O.D. = 14.5mm (0.570").
* Material = PA6 (Nylon) Temp. Range:-40C to +80C.
* (**) Locks onto # 71445, # 70361 power connectors. Twist type locking collar locks and seals connection. Prevents accidental disconnects.
* Closure cover protects inlet from weather / impact damage. Spare cover # 71440-B available.

70170-3C

EUROPEAN "SCHUKO" 16A-250V CEE 7/3 TYPE F (EU1-16R) THREE OUTLET SPLASHPROOF RUBBER CONNECTOR (***), IP44, FLIP LID CLOSURE COVERS, "T" SHAPE BODY, IMPACT RESISTANT. BLACK.
Notes:
* Max cord O.D. = 15mm (0.590").
* (***) with integral hanger bracket.

70170-3CS

EUROPEAN SCHUKO 16A-250V, 50/60 Hz, IP44, THREE (45 ANGLE) OUTLET POWER STRIP, IN-LINE CONNECTOR (***), CEE 7/3 TYPE F (EU1-16R), FLIP LID CLOSURE COVERS, IMPACT RESISTANT (*). BLACK.
Notes:
* (*) Elastomer rubber.
* Max cord O.D. = 10mm (0.394").
* #70170-3CS PDU horizontal rack mountable. Use #52019, #52019-BLK mounting plates.
* (***) with integral hanger bracket.

70170-3CA

EUROPEAN SCHUKO 16 AMPERE-250 VOLT, CEE 7/3 TYPE F (EU1-16R) THREE OUTLET, IP54 RUBBER CONNECTOR (***), "SNAP SHUT" CLOSURE LIDS. BLACK.
Notes:
* (***) with integral hanger bracket.

70120

EUROPEAN "SCHUKO" CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF (IP54) POWER OUTLET, PANEL OR WALL BOX MOUNT. GRAY FLIP LID, GRAY BASE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-BLK

EUROPEAN "SCHUKO" CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF (IP54) POWER OUTLET, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-BLU

EUROPEAN "SCHUKO" CEE 7/3 (EU1-16R) 16A-250V WEATHERPROOF OUTLET, SHUTTERED CONTACTS, PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-RED

EUROPEAN "SCHUKO" CEE 7/3 (EU1-16R) 16A-250V WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. RED.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54

EUROPEAN "SCHUKO" CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. GRAY/BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54BLK

EUROPE, EUROPEAN "SCHUKO" CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54BLU

EUROPE, EUROPEAN"SCHUKO" CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

70120-IP54RED

EUROPE, EUROPEAN "SCHUKO" CEE 7/3 16A-250V (EU1-16R) IP54 WEATHERPROOF OUTLET, PANEL OR WALL BOX MOUNT. BLACK WITH RED COVER.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.

36025

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 CONNECTOR (EU1-16R), 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)

70190

EUROPEAN CEE 7/7 (EU1-16P) "SCHUKO" TYPE E, F, 16A-250V WEATHERPROOF (IP44) POWER INLET. BLACK.
Notes:
* Accepts European #70161 (EU1-16R), French #71161 (FR1-16R) type connectors.
* European CEE 7/7 IP68 locking power inlets #71442, #71443, #71444 available. Prevents accidental disconnects.

36006

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 TYPE F CONNECTOR (EU1-16R), 1.8 METERS (6 FEET) (72") LONG. BLACK.
Length: 1.8 METERS (6 FEET)

36010

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 TYPE F CONNECTOR (EU1-16R), 3.05 METERS (10 FEET) (120") LONG. BLACK.
Length: 3.05 METERS (10 FEET)

36010-WP

EUROPEAN SCHUKO EXTENSION CORD, IP44 WEATHERPROOF, 16A-250V, CEE 7/7 TYPE E, F PLUG, (EU1-16P) AND CEE 7/3 TYPE F CONNECTOR (EU1-16R), SHUTTERED CONTACTS, WEATHERPROOF CLOSURE COVER, 3.05 METERS (10 FEET) (120") LONG. BLACK.
Length: 3.05 METERS (10 FEET)

36015

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 CONNECTOR (EU1-16R), 4.6 METERS (15 FEET) (180") LONG. BLACK.
Length: 4.6 METERS (15 FEET)

36015-WP

EUROPEAN SCHUKO EXTENSION CORD, IP44 WEATHERPROOF, 16A-250V, CEE 7/7 TYPE E, F PLUG, (EU1-16P) AND CEE 7/3 TYPE F CONNECTOR (EU1-16R), SHUTTERED CONTACTS, WEATHERPROOF CLOSURE COVER, 4.6 METERS (15 FEET) (180") LONG. BLACK.
Length: 4.6 METERS (15 FEET)

36025

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 CONNECTOR (EU1-16R), 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)

36025-WP

EUROPEAN SCHUKO EXTENSION CORD, IP44 WEATHERPROOF, 16A-250V, CEE 7/7 TYPE E, F PLUG, (EU1-16P) AND CEE 7/3 TYPE F CONNECTOR (EU1-16R), SHUTTERED CONTACTS, WEATHERPROOF CLOSURE COVER, 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)

36050

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 CONNECTOR (EU1-16R), 15.24 METERS (50 FEET) (600") LONG. BLACK.
Length: 15.24 METERS (50 FEET)

36050-WP

EUROPEAN SCHUKO EXTENSION CORD, IP44 WEATHERPROOF, 16A-250V, CEE 7/7 TYPE E, F PLUG, (EU1-16P) AND CEE 7/3 TYPE F CONNECTOR (EU1-16R), SHUTTERED CONTACTS, WEATHERPROOF CLOSURE COVER, 15.24 METERS (50 FEET) (600") LONG. BLACK.
Length: 15.24 METERS (50 FEET)

36075

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 TYPE F CONNECTOR (EU1-16R), 22.86 METERS (75 FEET) (900") LONG. BLACK.
Length: 22.86 METERS (75 FEET)

36075-WP

EUROPEAN SCHUKO EXTENSION CORD, IP44 WEATHERPROOF, 16A-250V, CEE 7/7 TYPE E, F PLUG, (EU1-16P) AND CEE 7/3 TYPE F CONNECTOR (EU1-16R), SHUTTERED CONTACTS, WEATHERPROOF CLOSURE COVER, 22.86 METERS (75 FEET) (900") LONG. BLACK.
Length: 22.86 METERS (75 FEET)

36100

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V , CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 CONNECTOR (EU1-16R), 30.5 METERS (100 FEET) (1,200") LONG. BLACK.
Length: 30.5 METERS (100 FEET)

36100-WP

EUROPEAN SCHUKO EXTENSION CORD, IP44 WEATHERPROOF, 16A-250V, CEE 7/7 TYPE E, F PLUG, (EU1-16P) AND CEE 7/3 TYPE F CONNECTOR (EU1-16R), SHUTTERED CONTACTS, WEATHERPROOF CLOSURE COVER, 30.5 METERS (100 FEET) (1,200") LONG. BLACK.
Length: 30.5 METERS (100 FEET)

36150

EUROPEAN SCHUKO EXTENSION CORD, 16A-250V, CEE 7/7 TYPE E, F PLUG (EU1-16P), CEE 7/3 TYPE F CONNECTOR (EU1-16R), 45.7 METERS (150 FEET) (1,800") LONG. BLACK.
Length: 45.7 METERS (150 FEET)

36150-WP

EUROPEAN SCHUKO EXTENSION CORD, IP44 WEATHERPROOF, 16A-250V, CEE 7/7 TYPE E, F PLUG, (EU1-16P) AND CEE 7/3 TYPE F CONNECTOR (EU1-16R), SHUTTERED CONTACTS, WEATHERPROOF CLOSURE COVER, 45.7 METERS (150 FEET) (1,800") LONG. BLACK.
Length: 45.7 METERS (150 FEET)

36006-RCD

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 GFCI /RCD 30mA TRIP "DOWN ANGLE" (EU1-16P) TYPE E PLUG, TEST / RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 1.8 METERS (6 FEET) (72") LONG. BLACK.
Length: 1.8 METERS (6 FEET)

36010-RCD

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 GFCI /RCD 30mA TRIP "DOWN ANGLE" (EU1-16P) TYPE E PLUG, TEST / RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 3.05 METERS (10 FEET) (120") LONG. BLACK.
Length: 3.05 METERS (10 FEET)

36015-RCD

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 GFCI /RCD 30mA TRIP "DOWN ANGLE" (EU1-16P) TYPE E PLUG, TEST / RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 4.6 METERS (15 FEET) (180") LONG. BLACK.
Length: 4.6 METERS (15 FEET)

36025-RCD

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 GFCI /RCD 30mA TRIP "DOWN ANGLE" (EU1-16P) TYPE E PLUG, TEST / RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)

36050-RCD

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 GFCI /RCD 30mA TRIP "DOWN ANGLE" (EU1-16P) TYPE E PLUG, TEST / RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 15.24 METERS (50 FEET) (600") LONG. BLACK.
Length: 15.24 METERS (50 FEET)

36075-RCD

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 GFCI /RCD 30mA TRIP "DOWN ANGLE" (EU1-16P) TYPE E PLUG, TEST / RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 22.86 METERS (75 FEET) (900") LONG. BLACK.
Length: 22.86 METERS (75 FEET)

36100-RCD

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 GFCI /RCD 30mA TRIP "DOWN ANGLE" (EU1-16P) TYPE E PLUG, TEST / RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 30.5 METERS (100 FEET) (1,200") LONG. BLACK.
Length: 30.5 METERS (100 FEET)

36006-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 1.8 METERS (6 FEET) (72") LONG. BLACK.
Length: 1.8 METERS (6 FEET)

36010-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 TYPE E (EU1-16P) PLUG WITH IN-LINE GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 TYPE F (EU1-16R) CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 3.05 METERS (10 FEET) (120") LONG. BLACK.
Length: 3.05 METERS (10 FEET)

36015-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 TYPE E (EU1-16P) PLUG WITH IN-LINE GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 TYPE F (EU1-16R) CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 4.6 METERS (15 FEET) (180") LONG. BLACK.
Length: 4.6 METERS (15 FEET)

36025-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 TYPE E (EU1-16P) PLUG WITH "IN-LINE" GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 TYPE F (EU1-16R) CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)

36050-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 TYPE E (EU1-16P) PLUG WITH IN-LINE GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 TYPE F (EU1-16R) CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 15.24 METERS (50 FEET) (600") LONG. BLACK.
Length: 15.24 METERS (50 FEET)

36075-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 TYPE E (EU1-16P) PLUG WITH IN-LINE GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 TYPE F (EU1-16R) CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 22.86 METERS (75 FEET) (900") LONG. BLACK.
Length: 22.86 METERS (75 FEET)

36100-RCDS30

EUROPEAN SCHUKO GFCI / RCD 16A-250V IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 30mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 30.5 METERS (100 FEET) (1,200"). LONG. BLACK.
Length: 30.5 METERS (100 FEET)

36006-RCDS10

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 10mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 1.8 METERS (6 FEET) (72") LONG. BLACK.
Length: 1.8 METERS (6 FEET)

36010-RCDS10

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 10mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 3.05 METERS (10 FEET) (120") LONG. BLACK.
Length: 3.05 METERS (10 FEET)

36015-RCDS10

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 10mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 4.6 METERS (15 FEET) (180") LONG. BLACK.
Length: 4.6 METERS (15 FEET)

36025-RCDS10

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 10mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 7.6 METERS (25 FEET) (300") LONG. BLACK.
Length: 7.6 METERS (25 FEET)

36050-RCDS10

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH "IN-LINE" GFCI /RCD, 10mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 15.24 METERS (50 FEET) (600") LONG. BLACK.
Length: 15.24 METERS (50 FEET)

36075-RCDS10

EUROPEAN SCHUKO GFCI / RCD 16 AMPERE-250 VOLT IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 10mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 22.86 METERS (75 FEET) (900") LONG. BLACK.
Length: 22.86 METERS (75 FEET)

36100-RCDS10

EUROPEAN SCHUKO GFCI / RCD 16A-250V IP44 RATED EXTENSION CORD, SCHUKO CEE 7/7 (EU1-16P) TYPE E PLUG WITH IN-LINE GFCI /RCD, 10mA TRIP, TEST/RESET BUTTON, SCHUKO CEE 7/3 (EU1-16R) TYPE F CONNECTOR WITH WEATHERPROOF CLOSURE COVER, 30.5 METERS (100 FEET) (1,200") LONG. BLACK.
Length: 30.5 METERS (100 FEET)

70141

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM, RUSSIA 16 AMPERE-250 VOLT CEE 7/7 (EU1-16P) TYPE E, F PLUG (4.8mm DIA. PINS), IP20 RATED, O.D. CORD GRIP = 10.4mm (0.409") DIA., BLACK.
Notes:
* European Schuko "Locking Plugs" # 71441, # 70341-N are listed below. Prevents accidental disconnect.

70161

EUROPEAN SCHUKO 16A-250V TYPE F, CEE 7/3 (EU1-16R) IN-LINE CONNECTOR, MAX. CORD O.D. = 13mm (0.510"), BLACK.
Notes:
* European Schuko "Locking Connector" # 71445 is listed below. Prevents accidental disconnects.

70151

EUROPEAN SCHUKO, GERMANY, FRANCE, BELGIUM (EU1-16P) 16A-250V CEE 7/7, DIN / VDE 0620, IEC 60884 TYPE E, F "ELAMID PLASTIC" PLUG, 4.8 mm DIA. PINS, IP44 RATED, IK08 RATED, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., BLACK.
Notes:
*ELAMID Plastic Material Features: -40C to +80C rated, UV protection, chemical and impact resistant.
* European Schuko "Locking Plugs" # 71441, # 70341-N are listed below. Prevents accidental disconnect.

70162

EUROPEAN SCHUKO, GERMANY, (EU1-16R) 16A-250V CEE 7/3, DIN / VDE 0620, IEC 60884 TYPE F, "ELAMID PLASTIC" CONNECTOR, IP20 RATED, SHUTTERED CONTACTS, UV PROTECTION, CHEMICAL AND IMPACT RESISTANT, TERMINALS ACCEPT 2.5mm CONDUCTORS, MAX. CORD O.D. = 0.492" DIA., BLACK.
Notes:
*ELAMID Plastic Material Features: -40C to +80C rated, UV protection, chemical and impact resistant.

70140-RCD10

EUROPEAN SCHUKO 16A-230V (3680W), 50Hz, GFCI /RCD (PRCD-S) 10mA TRIP TYPE E, F CEE 7/7 (EU1-16P) ANGLE PLUG, IP54 RATED. BLACK.

70140-RCD30

EUROPEAN SCHUKO CEE 7/7 GFCI (RCD) 16A-230V ANGLE PLUG, TYPE E, F (EU1-16P), 50Hz, 30mA TRIP, IP54 RATED. BLACK.

70140-PRCD-10MA

EUROPEAN, GERMANY, FRANCE, "SCHUKO" CEE 7/7 (EU1-16P) (FR1-16P) PORTABLE GFCI / RCD (PRCD-S) PLUG ADAPTER, 10mA TRIP, 16A-250V, 50Hz / 60Hz, TYPE E, F, (EU1-16R) POWER OUTLET, IP20 RATED. BLACK. APPROVALS: GS (INTERTEK), CE MARK.
Notes:
* Operating temp. = -25C to +40C.
* Plug adapter connects with Germany, France, Belgium power outlets and CEE 7/3, CEE 7/5 type outlets used in other countries.
* 30mA trip version = #70140-PRCD-30MA available.
* 10mA and 30mA British, UK versions available = #72140-PRCD-10MA, #72140-PRCD-30MA.
* Requires reset after power failure. Not for use on freezers, refrigerators, life support equipment or equipment where power must be maintained.
