Japan Power Cords - AC Cables

  Japan Power Cords and Power Supply Cord Sets
Japan Power Cords 10 Amp  JA1-15P, JIS 8303, PSE, JET, 15 Amp 125 Volt AC, 2 Pole 3 Wire Grounding, Type B Plug
Japan Power Cords 7 Amp  Japan Non-Grounded, 2.5 Amp 125 Volt AC, 2 Pole 2 Wire Non-Grounding

Specification Data: Japan Power Cords, AC Cables, Type B Plug

Plug StandardJA1-15P, JIS 8303, PSE, JET, Type B PlugJapan Power Cords and AC Cables
Connector StandardsIEC 60320 (320) C-13, C-13 Locking, C-19, C-19 Locking, C-5, C-7, C-15, Unterminated
Cordage StandardsHVCTF, VCTF, VFF
Conductor Size / Rating0.75 mm @ 7 ampere, 1.25 mm @ 12 Ampere, 2.0 mm @ 15 Ampere
MaterialPVC, Jacket Color Black, Temperature 70C
Conductor Color CodeBrown, Blue, Green/Yellow (3 wire); Brown, Blue (2 wire)
Jacket O.D. (Approx.)8.0 mm = 3 x 0.75 mm, 8.7 mm = 3 x 1.25mm, 9.3 mm = 3 x 2.0 mm
Substances ComplianceREACH, RoHS Compliant

Power Cord Notes: Japan Type B power cords are black as standard color. Japan power cords in white or gray are special order. Custom length and shielded Japan AC power cables available. Terminated, custom stripping, hanked Japan cords available. IEC 60320 C-15 120C connector available on some Japan AC power cords.

Japan Power Cords - AC Cables

Japan Power Cords, Detachable Cord Sets to IEC 60320 Straight C-13 Connector
JIS 8303, PSE, JET, Type B Plug
~ Click Part Number for approvals, specifications and print. ~

Part No.Rating DescriptionLength
81200 12A 125V AC Straight
C-13 Connector
1.25mm Cordage
2.5 m
81202 15A 125V AC Straight
C-13 Connector
2.00mm Cordage
2.5 m
Cordage - HVCTF - CE Mark
Japan plug to straight C-13 connector - Japan Power Cord
Japan Power Cords, Type B Plug
JA1-15P       "CE" Mark       IEC 60320 C-13

Japan Power Cords, Detachable Cord Sets to IEC 60320 Left-Angle C-13 Connector
JIS 8303, PSE, JET, Type B Plug
~ Click Part Number for approvals, specifications and print. ~

Part No.Rating DescriptionLength
81200-LA 12A 125V AC Left-Angle
C-13 Connector
1.25mm Cordage
2.5 m
Cordage - HVCTF - CE Mark
Japan plug to left-angle C-13 connector - Japan Power Cord
Japan Power Cords, Type B Plug
JA1-15P       "CE" Mark       IEC 60320 C-13

Japan Power Cords, Detachable Cord Sets to IEC 60320 Right-Angle C-13 Connector
JIS 8303, PSE, JET, Type B Plug
~ Click Part Number for approvals, specifications and print. ~

Part No.Rating DescriptionLength
81200-RA 12A 125V AC Right-Angle
C-13 Connector
1.25mm Cordage
2.5 m
Cordage - HVCTF - CE Mark
Japan plug to right-angle C-13 connector - Japan Power Cord
Japan Power Cords, Type B Plug
JA1-15P       "CE" Mark       IEC 60320 C-13

Japan Power Cords, Detachable Cord Sets to IEC 60320 Straight C-19 Connector
JIS 8303, PSE, JET, Type B Plug
~ Click Part Number for approvals, specifications and print. ~

Part No.Rating DescriptionLength
80650 15A 125V AC Straight
C-19 Connector
2.00mm Cordage
2.5 m
Cordage - VCTF - CE Mark
Japan plug to straight C-19 connector - Japan Power Cord
Japan Power Cords, Type B Plug
JA1-15P       "CE" Mark       IEC 60320 C-19

Japan Power Cords, Detachable Cord Sets to IEC 60320 Straight C-5 Connector
JIS 8303, PSE, JET, Type B Plug
~ Click Part Number for approvals, specifications and print. ~

Part No.Rating DescriptionLength
81295 7A 125V AC Straight
C-5 Connector
0.75mm Cordage
1.8 m
Cordage - VCTF - CE Mark
Japan plug to straight C-5 connector - Japan Power Cord
Japan Power Cords, Type B Plug
JA1-15P       "CE" Mark       IEC 60320 C-7

Japan Power Cords, Detachable Cord Sets to IEC 60320 Straight C-7 Connector
JA1-15P Non-Grounded
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescriptionLength
82900 7A 125V ACStraight C-7 Connector1.8 m
Cordage - VFF 0.75mm - CE Mark
JA1-15P Non-Grounded to straight C-7 connector - Japan Power Cord
Japan Power Cords
JA1-15P Non-Grounded       "CE" Mark       IEC 60320 C-7

Japan Power Cords, Power Supply Cord Sets to Unterminated Cord End
JIS 8303, PSE, JET, Type B Plug
~ Click Part Number for approvals, specifications and print. ~

Part No.RatingDescription / ConductorsLength
812407A 125V ACStraight Plug
0.75 mm Cordage
2.5 m
8125012A 125V ACStraight Plug
1.25 mm Cordage
2.5 m
8126015A 125V ACStraight Plug
2.00 mm Cordage
2.5 m
Cordage - VCTF, HVCTF - CE Mark
Japan Power Cord - Japan plug to Unterminated End
Japan Power Cords, Type B Plug
  JA1-15P       "CE" Mark       Unterminated
     Japan power cords and power AC cables, produced by International Configurations meet Japan quality standards and comply with current RoHS and REACH requirements. International Configurations manufactures and supplies power cords and AC cables for use in Japan and all other Countries throughout the world. Utilize our Japan power cord links above to select and view product specification data and download power cord prints.
