Australia Power Cords - AC Cables
Australia Power Cords and Power Supply Cord Sets
AU1-10P, AS NZS 4417, AS NZS 3112, 10 Amp 250 Volt AC, 2 Pole 3 Wire Grounding, Type I Plug
AU2-15P, AS NZS 4417, AS NZS 3112, 15 Amp 250 Volt AC, 2 Pole 3 Wire Grounding, Type I Plug
AU1-10P Non-Grounded, 2.5 Amp 250 Volt AC, 2 Pole 2 Wire Non-Grounding
Specification Data: Australia Power Cords, AC Cables, Type I Plug
 |
|
|
| Plug Standard | AU1-10P, AS NZS 4417, AS NZS 3112, Type I Plug AU2-15P, AS NZS 4417, AS NZS 3112, Type I Plug |  |
|---|---|---|
| Connector Standards | IEC 60320 (320) C-13, C-13 Locking, C-19, C-19 Locking, C-5, C-7, C-15, Unterminated | |
| Cordage Standards | GTSA, H05VV-F3G, H03VV-F3G, H03VV-H2, H05VV-H2, H05VV-F2 | |
| Conductor Size / Rating | 0.75 mm @ 6 Ampere, 1.0 mm @ 10 Ampere, 1.5mm @ 16 Ampere | |
| Material | PVC, Jacket Color Black, Temperature 70C | |
| Conductor Color Code | Brown, Blue, Green/Yellow (3 wire); Brown, Blue (2 wire) | |
| Jacket O.D. (Approx.) | 6.4 mm = 3 x 0.75 mm, 7.2 mm = 3 x 1.0mm, 8.3 mm = 3 x 1.5 mm | |
| Substances Compliance | REACH, RoHS Compliant | |
| Power Cord Notes: | Australia Type I power cords are black as standard color. Australia power cords in white or gray are special order. Custom length and shielded Australia AC power cables available. Terminated, custom stripping, hanked Australia cords available. IEC 60320 C-15 120C connector available on some Australia AC power cords. | |
